7-9
Specifications and Regulatory Information
Specifications
General Specifications
Option 004/005 EELED Sources
HP 86140A and HP 86142A
Benchtop
HP 86143A and HP 86145A
Portable
Dimensions
222 mm H × 425 mm W × 427 mm D
(8.8 in × 16.8 in × 16.8 in)
163 mm H × 325 mm W × 427 mm D
(6.4 in × 12.8 in × 16.8 in)
Weight
16.5 kg (36 lb) 14.5 kg (31 lb)
Environmental
Temperature
a
a. Floppy disk and printer operating temperature range 0
°
C to 45
°
C.
Operating: 0
°
C to 55
°
C; Storage: –40
°
C to 70
°
C
Humidity Operating: < 95% RH; Storage: Non-condensing
Altitude Up to 15,000 feet (4,572 meters)
EMI Conducted and radiated interference is in compliance with
CISPR Publication 11,
IEC 801-3, IEC 801-4, and IEC 555-2
Power Requirements
Voltage and Frequency 90 Vac to 260 Vac, 44 to 444 Hz
Maximum Power Consumption 230 W
HP 86140A and HP 86142A
Minimum Spectral Power Density
a
a. Temperature range 0
°
C to 45
°
C.
1540 to 1560 nm (Option 005) > –40 dBm/nm (100 nW/nm)
1470 to 1620 nm (Option 005) > –60 dBm/nm (1 nW/nm)
1300 to 1320 nm (Option 004)
1540 to 1560 nm (Option 004)
> –40 dBm/nm (100 nW/nm)
> –40 dBm/nm (100 nW/nm)
1250 to 1620 nm (Option 004) > –60 dBm/nm (1 nW/nm)
Return Loss
With straight connector > 25 dB
Stability (ambient temperature <
±
1
°
C)
Over 15 minutes
<
±
0.02 dB
Over 6 hours
< ±
0.05 dB
book.book Page 9 Monday, January 31, 2000 10:34 AM
