HP b2600 Upgrade Instructions

Upgrading Your System
Removing the Air Divider
Removing the Air Divider
1. Remove the PCI retainer clip by pulling evenly in the direction of the “Pull” tabs on the clip and lifting it
out of the workstation.
Figure 2-12 Removing the Air Divider
PCI Retainer Clip
Air Divider
2. Remove the two T-15 Torx screws that secure the air divider to the chassis.
3. Note the placement of the air divider for later reference.
4. Grasp the air divider and pull it straight up and out toward you. Set it aside with its screws.
18
Chapter 2
