Interpreting POST Diagnostic Front Panel LEDs and
Audible Codes
This section covers the front panel LED codes as well as the audible codes that may occur before or
during POST that do not necessarily have an error code or text message associated with them.
WARNING! When the computer is plugged into an AC power source, voltage is always applied to
the system board. To reduce the risk of personal injury from electrical shock and/or hot surfaces, be
sure to disconnect the power cord from the wall outlet and allow the internal system components to cool
before touching.
NOTE: If you see flashing LEDs on a PS/2 keyboard, look for flashing LEDs on the front panel of the
computer and refer to the following table to determine the front panel LED codes.
Recommended actions in the following table are listed in the order in which they should be performed.
Not all diagnostic lights and audible codes are available on all models.
Table A-2 Diagnostic Front Panel LEDs and Audible Codes
Activity Beeps Possible Cause Recommended Action
Green Power LED On. None Computer on. None
Green Power LED flashes every
two seconds.
None Computer in Suspend to
RAM mode (some models
only) or normal Suspend
mode.
None required. Press any key or move the mouse
to wake the computer.
Red Power LED flashes two
times, once every second,
followed by a two second
pause. Beeps stop after fifth
iteration but LEDs continue until
problem is solved.
2 Thermal protection
activated:
Air flow is restricted, a fan
may not be functioning, or
the heatsink is not
properly attached.
1. Clean the air vents on the front, back, or any
other vented side of the computer.
2. Ensure that there is a 10.2 cm (4 in)
clearance on all vented sides of the
computer to permit the required airflow.
3. Ensure that computers are not so near each
other that they are subject to each other's re-
circulated or preheated air.
4. If the computer is within an enclosure, ensure
that there is proper intake and exhaust
ventilation for the enclosure.
5. If a message appears on the screen
indicating that a fan is not working, replace
the fan.
6. Ensure that the heat sink is properly
attached.
Red Power LED flashes three
times, once every second,
followed by a two second
pause. Beeps stop after fifth
iteration but LEDs continue until
problem is solved.
3 Processor not installed (not
an indicator of bad
processor).
1. Check to see that the processor is present.
2. Reseat the processor.
106 Appendix A POST Error Messages

HP Compaq 6000 Pro Specifications

General

Tcase	72.4 °C
Bus type	FSB
Stepping	C0
Processor cache	6 MB
Processor cores	2
Processor model	E8500
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo E8000 Series
Processor socket	LGA 775 (Socket T)
Processor codename	Wolfdale
Processing Die size	107 mm²
Processor frequency	3.16 GHz
Processor cache type	L2
Processor lithography	45 nm
Processor system type	DP
Processor manufacturer	Intel
Processor front side bus	1333 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	65 W
Processor core voltage (AC)	0.850/1.3625 V
Number of processors installed	1
CPU multiplier (bus/core ratio)	9.5
Number of Processing Die Transistors	410 M
Platform	PC
LightScribe	Yes
Power supply type	AC/DC
Security features	TPM 1.2
External drive bays	2 x 5.25\
Internal drive bays	2 x 3.5\
Networking features	Gigabit Ethernet
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Audio system	Realtek ALC261
Motherboard chipset	Intel® Q43
Audio output channels	2.0 channels
Memory slots	4x DIMM
Internal memory	4 GB
Internal memory type	DDR3-SDRAM
Maximum internal memory	16 GB
Memory layout (slots x size)	2 x 2 GB
HDD size	3.5 \
HDD speed	7200 RPM
HDD interface	SATA
Optical drive type	DVD-RW
Total storage capacity	500 GB
Discrete graphics card model	Not available
On-board graphics card model	Intel® GMA 4500
On-board graphics card family	Intel® GMA
Operating system installed	Windows 7 Professional
USB 2.0 ports quantity	10
Firewire (IEEE 1394) ports	0
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Chassis type	Micro Tower
Product color	Black
Country of origin	China
Cable lock slot type	Kensington
Number of 3.5\" bays	3
Power supply	320 W
Processor code	SLAPK
Processor ARK ID	33911
Processor package size	37.5 x 37.5 mm

Weight and Dimensions

Depth	430 mm
Width	176 mm
Height	377 mm
Weight	9300 g
