Tools and Software Requirements
To service the computer, you need the following:
●
Torx T-15 screwdriver (HP screwdriver with bits, PN 161946-001)
●
Flat-bladed screwdriver (may sometimes be used in place of the Torx screwdriver)
●
Phillips #2 screwdriver
●
Diagnostics software
●
HP tamper-resistant T-15 wrench (Smart Cover FailSafe Key, PN 166527-001) or HP tamper-
resistant bits (Smart Cover FailSafe Key, PN 166527-002)
Screws
The screws used in the computer are not interchangeable. They may have standard or metric threads
and may be of different lengths. If an incorrect screw is used during the reassembly process, it can
damage the unit. HP strongly recommends that all screws removed during disassembly be kept with the
part that was removed, then returned to their proper locations.
CAUTION: As each subassembly is removed from the computer, it should be placed away from the
work area to prevent damage.
Cables and Connectors
Most cables used throughout the unit are flat, flexible cables. These cables must be handled with care
to avoid damage. Apply only the tension required to seat or unseat the cables during insertion or
removal from the connector. Handle cables by the connector whenever possible. In all cases, avoid
bending or twisting the cables, and ensure that the cables are routed in such a way that they cannot be
caught or snagged by parts being removed or replaced.
CAUTION: When servicing this computer, ensure that cables are placed in their proper location
during the reassembly process. Improper cable placement can damage the computer.
Hard Drives
Handle hard drives as delicate, precision components, avoiding all physical shock and vibration. This
applies to failed drives as well as replacement spares.
●
If a drive must be mailed, place the drive in a bubble-pack mailer or other suitable protective
packaging and label the package “Fragile: Handle With Care.”
●
Do not remove hard drives from the shipping package for storage. Keep hard drives in their
protective packaging until they are actually mounted in the CPU.
●
Avoid dropping drives from any height onto any surface.
●
If you are inserting or removing a hard drive, turn off the computer. Do not remove a hard drive
while the computer is on or in standby mode.
Service Considerations
31

HP Compaq 6000 Pro Specifications

General

Tcase	72.4 °C
Bus type	FSB
Stepping	C0
Processor cache	6 MB
Processor cores	2
Processor model	E8500
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo E8000 Series
Processor socket	LGA 775 (Socket T)
Processor codename	Wolfdale
Processing Die size	107 mm²
Processor frequency	3.16 GHz
Processor cache type	L2
Processor lithography	45 nm
Processor system type	DP
Processor manufacturer	Intel
Processor front side bus	1333 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	65 W
Processor core voltage (AC)	0.850/1.3625 V
Number of processors installed	1
CPU multiplier (bus/core ratio)	9.5
Number of Processing Die Transistors	410 M
Platform	PC
LightScribe	Yes
Power supply type	AC/DC
Security features	TPM 1.2
External drive bays	2 x 5.25\
Internal drive bays	2 x 3.5\
Networking features	Gigabit Ethernet
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Audio system	Realtek ALC261
Motherboard chipset	Intel® Q43
Audio output channels	2.0 channels
Memory slots	4x DIMM
Internal memory	4 GB
Internal memory type	DDR3-SDRAM
Maximum internal memory	16 GB
Memory layout (slots x size)	2 x 2 GB
HDD size	3.5 \
HDD speed	7200 RPM
HDD interface	SATA
Optical drive type	DVD-RW
Total storage capacity	500 GB
Discrete graphics card model	Not available
On-board graphics card model	Intel® GMA 4500
On-board graphics card family	Intel® GMA
Operating system installed	Windows 7 Professional
USB 2.0 ports quantity	10
Firewire (IEEE 1394) ports	0
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Chassis type	Micro Tower
Product color	Black
Country of origin	China
Cable lock slot type	Kensington
Number of 3.5\" bays	3
Power supply	320 W
Processor code	SLAPK
Processor ARK ID	33911
Processor package size	37.5 x 37.5 mm

Weight and Dimensions

Depth	430 mm
Width	176 mm
Height	377 mm
Weight	9300 g
