Operations 25
c.
Lift the assembly to unseat the PCI riser boards, and then remove the assembly.
Install the PCI riser board assembly
CAUTION: To prevent damage to the server or expansion boards, power down the server and
remove all AC power cords before removing or installing the PCI riser board assembly.
1. Align the PCI riser boards with the corresponding connectors on the system board, and then install
the assembly.
2. Tighten the four PCI riser board assembly thumbscrews.
3. Install the air baffle (on page 23).
4. Install the BBWC battery pack, if removed ("Installing the BBWC battery pack" on page 58).
5. Install the access panel (on page 22).
6. Slide the server into the rack.
