7-28
Configuring RADIUS Server Support for Switch Services
Configuring and Using Dynamic (RADIUS-Assigned) Access Control Lists
Figure 7-4. Example of Switch Identity Information for a FreeRADIUS Application
3. For a given client username/password pair or MAC address, create an ACL
by entering one or more ACEs in the FreeRADIUS “users” file. Remember
that every ACL you create automatically includes an implicit deny in ip
from any to any ACE. For example, suppose that you wanted to create
identical ACL support for the following:
a client having a username of “mobilE011” and a password of
“run10kFast”
a client having a MAC address of 08 E9 9C 4F 00 19
The ACL in this example must achieve the following:
permit http (TCP port 80) traffic from the client to the device at
10.10.10.101
deny http (TCP port 80) traffic from the client to all other devices
permit all other traffic from the client to all other devices
To configure the above ACL, you would enter the username/password and
ACE information shown in figure 7-5 into the FreeRADIUS “users” file.
client 10.10.10.125
nastype = other
secret = 1234
Note: The key configured in the switch and the
secret configured in the RADIUS server
supporting the switch must be identical. Refer
to the chapter titled “RADIUS Authentication
and Accounting” in the latest Access Security
Guide for your switch.
