HP EliteDesk 705 G2 Small Form Factor User Manual

Memory
Description
8-GB, PC3-12800
4-GB, PC3-12800
2-GB, PC3-12800
The computer comes with low power double data rate 3 synchronous dynamic random access memory
(DDR3L-SDRAM) dual inline memory modules (DIMMs). It also supports standard DDR3-SDRAM DIMMS.
DIMMs
The memory sockets on the system board can be populated with up to four industry-standard DIMMs. These
memory sockets are populated with at least one preinstalled DIMM. To achieve the maximum memory
support, you can populate the system board with up to 32-GB of memory congured in a high-performing
dual channel mode.
DDR3/DDR3L-SDRAM DIMMs
For proper system operation, the DIMMs must be:
●
industry-standard 240-pin
●
unbuered non-ECC PC3-12800 DDR3/DDR3L-1600 MHz-compliant
●
1.5 volt DDR3-SDRAM DIMMs or 1.35 volt DDR3L-SDRAM (Low Power) DIMMs
The DIMMs must also:
●
support CAS latency 11 DDR3/DDR3L 1600 MHz (11-11-11 timing)
●
contain the mandatory JEDEC SPD information
In addition, the computer supports:
●
512-Mbit, 1-Gbit, and 2-Gbit non-ECC memory technologies
●
single-sided and double-sided DIMMs
●
DIMMs constructed with x8 and x16 DDR devices; DIMMs constructed with x4 SDRAM are not supported
NOTE: The system will not operate properly if you install unsupported DIMMs.
Populating DIMM sockets
There are four DIMM sockets on the system board, with two sockets per channel. The sockets are labeled
DIMM1, DIMM2, DIMM3, and DIMM4. Sockets DIMM1 and DIMM2 operate in memory channel B. Sockets DIMM3
and DIMM4 operate in memory channel A.
The system will automatically operate in single channel mode, dual channel mode, or ex mode, depending
on how the DIMMs are installed.
NOTE: Single channel and unbalanced dual channel memory congurations will result in inferior graphics
performance.
Memory 23
