HP EliteDesk 705 G2 Small Form Factor User Manual

Hood lock
The hood lock is attached to the rear of the chassis.
1. Prepare the computer for disassembly (Preparation for disassembly on page 19).
2. Remove the access panel (Access panel on page 20).
3. On the rear of the computer, remove the security screw that secures the lock.
NOTE: The security screw requires a special security wrench to remove.
4. From the inside of the computer, lift the hood lock out of the computer..
To install the hood lock, reverse the removal procedure.
When installing the hood lock, on the inside rear of the computer, insert the clips on the back of the lock into
the slots on the computer rear panel (1), and then rotate the lock down into place (2).
Hood lock 49
