HP EliteDesk 705 G2 Small Form Factor User Manual

5. Pull outward on the release lever at the rear of the drive (1) then slide the drive back until it stops and
pull it down and out of the drive bay (2).
6. If you are installing a new drive, refer to Installing a 2.5-inch hard drive on page 43. If you are not
installing a new drive, rotate the drive cage down and replace the access panel.
Installing a 2.5-inch hard drive
1. Prepare the computer for disassembly (Preparation for disassembly on page 19).
2. Remove the access panel (Access panel on page 20).
3. Install four black and blue M3 isolation mounting guide screws (two on each side of the drive).
NOTE: M3 metric isolation mounting guide screws can be purchased from HP.
When replacing a drive, transfer the four mounting screws from the old drive to the new drive.
Drives 43
