HP EliteDesk 705 G2 Small Form Factor User Manual

Drive positions
1 9.5mm slim optical drive bay
2 3.5-inch primary hard drive bay
3 3.5-inch secondary hard drive bay
4 2.5-inch hard drive bay
NOTE: The drive conguration on your computer may be dierent than the drive
conguration shown above.
To verify the type and size of the storage devices installed in the computer, run Computer Setup.
Installing and Removing Drives
When installing drives, follow these guidelines:
●
The primary Serial ATA (SATA) hard drive must be connected to the dark blue primary SATA connector on
the system board labeled SATA0.
●
Connect secondary hard drives and optical drives to one of the light blue SATA connectors on the system
board (labeled SATA1 and SATA2).
32 Chapter 4 Removal and replacement procedures – small form factor (SFF) chassis
