ENWW HP Jetdirect Configuration Page 205
Configuration Page Messages
HP Jetdirect Configuration/General Information
Information in this section provides general HP Jetdirect print
server configuration as described in Table 9.1
. For error messages,
see Table 9.11
.
Table 9.1 HP Jetdirect Configuration (1 of 2)
Message Description
STATUS: Current state of the HP Jetdirect print server.
I/O CARD READY, or READY: The HP Jetdirect print server
has successfully connected to the network and is awaiting
data.
I/O CARD INITIALIZING, or INITIALIZING: The
HP Jetdirect print server is initializing the network protocols.
For more information, see the status line for each protocol
on the configuration page.
I/O CARD NOT READY, or ERROR: There is a problem with
the print server or its configuration.
An error code and message is displayed if the print server
is not ready. For more information, see Table 9.11
.
MODEL NUMBER: The model number of the HP Jetdirect print server (for
example, J7951A)
HARDWARE
ADDRESS:
The 12-digit hexadecimal network hardware (MAC) address
of the HP Jetdirect print server installed in the printer or
device. This address is assigned by the manufacturer.
FIRMWARE VERSION: The firmware revision number of the HP Jetdirect print
server currently installed in the printer.
NETWORK
CONNECTION TYPE
(ew2400) Specifies the type of network connection:
Wireless or Wired.
DATA RATE
DETECTED
(ew2400) Specifies the network data rate depending on the
type of network connection:
1 - 54 Mbps (Wireless 802.11g)
10 Mbs, 100 Mbps (Wired 10/100Base-TX)
LINK CONFIG (ew2400) Specifies the active link communication mode:
802.11: Wireless 802.11g
10T HALF: 10 Mbps, half-duplex (wired port)
10T FULL: 10 Mbps, full-duplex (wired port)
100TX HALF: 100Mbps, half-duplex (wired port)
100TX FULL: 100Mbps, full-duplex (wired port)
