ENWW The HP Jetdirect EIO Control Panel Menu 249
Graphical Control Panel
Graphical control panels
typically display 18 characters
on a line, and as many as four
lines at a time. In addition,
scrolling may be supported to
allow display of additional
lines.
On graphical control panels, a numeric keypad and navigation
buttons are used to access HP Jetdirect menu items. For a
description of menu items and options, see Table B.2
.
Table B.2 HP Jetdirect Graphical Control Panel Menu (1 of 4)
Menu Item Options Description of settings
TCP/IP ENABLE ON: Enable the TCP/IP protocol
OFF: Disable the TCP/IP protocol
HOST NAME An alphanumeric string, up to 32 characters,
used to identify the device. This name is listed
on the Jetdirect configuration page. The
default host name is NPIxxxxxx, where
xxxxxx is the last six digits of the LAN
hardware (MAC) address.
CONFIG METHOD Specifies the method that TCP/IP parameters
will be configured on the Jetdirect print server.
● BOOTP: Use BootP (Bootstrap Protocol)
for automatic configuration from a BootP
server.
● DHCP: Use DHCP (Dynamic Host
Configuration Protocol) for automatic
configuration from a DHCP server. If
selected and a DHCP lease exists, DHCP
RELEASE and DHCP RENEW menus will
be available to set DHCP lease options.
● AUTO IP: Use automatic link-local IP
addressing. An address in the form
169.254.x.x will be automatically
assigned.
● MANUAL: Use the MANUAL SETTINGS
menu to configure TCP/IP parameters.
?
MENUS
+ XXXXXXXXXX
To Next Page
