HP J9833A User Manual

Index-1
Numerics
10/100BASE-TX ports
location on switch … 1-2
1000BASE-T
fiber-optic cable specifications … A-5
A
acoustic specifications … A-2
auto MDI/MDI-X operation … A-10, A-12
HP Auto-MDIX feature … A-8
B
back of switch
power connector … 1-5
basic troubleshooting tips … 4-1
blinking LEDs
error indications … 4-2, 4-4
buttons
Clear button … 1-5
Reset button … 1-5
C
cabinet
mounting the switch in … 2-6, 2-10, 2-12
cables
connecting cables to switch ports … 2-14
infrastructure requirements … 2-5
cables, twisted pair
category 3, 4, 5 … A-8
cross-over cable pin-out … A-11
MDI-X to MDI connections … A-10, A-12
MDI-X to MDI-X connections … A-11
pin-outs … A-10, A-12
straight-through cable pin-out … A-10, A-12
switch-to-computer connection … A-10, A-12
switch-to-switch or hub connection … A-11
cables, twisted-pair
HP Auto-MDIX feature … A-8
wiring rules … A-8
cables, twisted-pair connector pin-outs … A-8
cabling infrastructure … 2-5
Clear button
deleting passwords … 1-5
description … 1-5
location on switch … 1-2, 1-5
restoring factory default configuration … 1-5, 4-4
configuration
restoring factory defaults … 1-5
console port
location on switch … 1-2
cross-over cable
pin-out … A-11
D
deleting passwords … 1-5
description
front of switch … 1-2
LEDs … 1-4
switch … 1-1
E
electrical specifications, switch … A-1
environmental specifications, switch … A-2
F
factory default configuration, restoring … 1-5
Fault LED
location on switch … 1-2
showing error conditions … 4-2
fiber-optic cables
1000BASE-T … A-5
front of switch … 1-2
10/100BASE-TX ports … 1-2
Clear button … 1-5
description … 1-2
network ports … 1-3
Reset button … 1-5
H
horizontal surface
mounting switch on … 2-13
