Color Quantity Length Thread Head diameter
Black 11 5.0 mm 2.0 mm 4.5 mm
Where used:
(1) Six captive screws (secured by C-clips) that secure the hard drive bay cover to the computer
(2) One captive screw (secured by a C-clip) that secure the WLAN module compartment cover to the
computer
(3) Two captive screws (secured by C-clips) that secure the memory module compartment cover to the
computer
(4) Two captive screws (secured by C-clips) that secure the TV tuner module compartment cover to the
computer
Phillips PM2.5×12.0 captive screw
Color Quantity Length Thread Head diameter
Silver 2 12.0 mm 2.5 mm 5.0 mm
Phillips PM2.5×12.0 captive screw 101
