Color Quantity Length Thread Head diameter
Silver 7 5.0 mm 2.0 mm 4.5 mm
Where used:
(1) Three captive screws (secured by C-clips) that secure the processor heat sink to the system board
(2) Four captive screws (secured by C-clips) that secure the video board heat sink to the system board
Phillips PM2.5×8.0 captive screw
Color Quantity Length Thread Head diameter
Silver 2 8.0 mm 2.5 mm 5.0 mm
Phillips PM2.5×8.0 captive screw 113
