Display assembly
Description Spare part number
20.1-inch, WSXGA BrightView display assembly (includes camera module and cable, microphones,
speakers, and WLAN antennae)
452299-001
20.1-inch, WUXGA BrightView display assembly (includes camera module and cable, microphones,
speakers, and WLAN antennae)
452300-001
Before removing the display assembly, follow these steps:
1.
Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2.
Disconnect all external devices connected to the computer.
3.
Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4.
Remove the battery (see
Battery on page 36).
5.
Disconnect the WLAN module antenna cables from the WLAN module (see
WLAN module
on page 44).
6.
Remove the following components:
a.
Hard drive (see
Hard drive on page 42)
b.
Optical drive (see
Optical drive on page 49)
c.
Keyboard (see
Keyboard on page 50)
d.
Hinge cover (see
Hinge cover on page 52)
e.
Rear cover (see
Rear cover on page 53)
f.
Top cover (see
Top cover on page 55)
Remove the display assembly:
1.
Close the computer and turn it upside down, with the front toward you.
60 Chapter 4 Removal and replacement procedures
