Component Description
(5) External monitor port Connects an external VGA monitor or projector.
(6) RJ-45 (network) jack Connects a network cable.
(7) HDMI port Connects an optional HDMI device.
(8) Combo eSATA/USB 2.0 port Connects an optional USB device or a high-performance eSATA
component, such as an eSATA external hard drive.
(9) USB 2.0 port Connects an optional USB device.
(10) ExpressCard/34 slot Supports an optional ExpressCard.
Bottom
Component Description
(1) Battery release latches (2) Release the battery from the battery bay.
(2) Battery bay Holds the battery.
Wireless antennas
Wireless antennas send and receive signals from one or more wireless devices. These antennas are
not visible from the outside of the computer.
8 Chapter 1 Notebook tour
