Port Status and Basic Configuration
Viewing Port Status and Configuring Port Parameters
Per-Port MDI
Operating Mode
Figure 10-7. Example of Displaying the Current MDI Operating Mode
Note Port Response to Switch Software Updates
1. Copper ports in auto-negotiation still default to auto-mdix mode.
2. Copper ports in forced speed/duplex default to mdix mode.
The default is auto-mdix. If the switch is reset to the factory defaults, these
ports are configured as auto-mdix. Use the following CLI command to change
the setting for individual ports:
interface < port-list > mdix-mode < automdix | mdi | mdix >
Viewing Transceiver Status
The show tech transceivers command allows you to:
â– Remotely identify transceiver type and revision number without having
to physically remove an installed transceiver from its slot.
â– Display real-time status information about all installed transceivers,
including non-operational transceivers.
10-15
