HP ProCurve 2610-PWR User Manual

Using the Web Browser Interface
Status Reporting Features
Figure 5-13.Example of Alert Log Detail View
The Status Bar
The Status Bar is displayed in the upper left corner of the web browser
interface screen. Figure 5-14 shows an expanded view of the status bar.
Status Indicator
Most Critical Alert Description
Product Name
Figure 5-14. Example of the Status Bar
The Status bar consists of four objects:
■ Status Indicator. Indicates, by icon, the severity of the most critical
alert in the current display of the Alert Log. This indicator can be one of
three shapes and colors as shown in the following table.
5-20

HP ProCurve 2610-PWR Specifications

General

Form Factor	Rack-mountable
Layer	Layer 2
Power over Ethernet (PoE)	Yes
PoE Budget	370W
Jumbo Frame Support	Yes
VLAN Support	Yes
Power Supply	Internal
Layer 3 Routing	No
Product Series	HP ProCurve 2610
Management	Web-based GUI, Command-line interface (CLI), SNMP
Operating Temperature	0°C to 45°C (32°F to 113°F)
Operating Humidity	10% to 90% non-condensing
MAC Address Table Size	16, 000 entries
Dimensions	44.25 x 25.4 x 4.39 cm (17.42 x 10 x 1.73 in)
