Configuring for Network Management Applications
Using SNMP Tools To Manage the Switch
Using the CLI To List Current SNMP Trap Receivers.
This command lists the currently configured trap receivers and the setting for
authentication traps (along with the current SNMP community name data —
see “SNMP Communities” on page 13-12).
Syntax: show snmp-server
Displays current community and trap receiver data.
In the next example, the show snmp-server command shows that the switch
has been previously configured to send SNMP traps to management stations
belonging to the “public”, “red-team”, and “blue-team” communities.
Example of
Community
Name Data (See
page 13-12.)
Example of Trap
Receiver Data
Authentication
Trap Setting
Figure 13-9. Example of Show SNMP-Server Listing
Configuring Trap Receivers
This command specifies trap receivers by community membership,
management station IP address, and the type of Event Log messages to send
to the trap receiver.
13-21
