Monitoring and Analyzing Switch Operation
Status and Counters Data
Menu Access to the MAC Address Views and Searches
Per-VLAN MAC-Address Viewing and Searching. This feature lets you
determine which switch port on a selected VLAN is being used to communi-
cate with a specific device on the network. The per-VLAN listing includes:
â– The MAC addresses that the switch has learned from network devices
attached to the switch
â– The port on which each MAC address was learned
1. From the Main Menu, select:
1. Status and Counters
5. VLAN Address Table
2. The switch then prompts you to select a VLAN.
3. Use the Space bar to select the VLAN you want, then press [Enter]. The
switch then displays the MAC address table for that VLAN:
Figure B-8. Example of the Address Table
To page through the listing, use N
ext page and Prev page.
B-13
