Power Over Ethernet (PoE) Operation
Planning and Implementing a PoE Configuration
For example, if you wanted to view the PoE status of port 5, you would use
show power-management 5 to display the data:
ProCurve(config)# show power-management 5
Status and Counters - Port Power Status for port 5
Power Enable : Yes
Priority : Low Configured Type :
Detection Status : Delivering Power Class : 0
Over Current Cnt : 0 MPS Absent Cnt : 2
Power Denied Cnt : 0 Short Cnt : 0
Voltage : 545 dV Current : 13 mA
Power : 711 mW
Figure 11-4. Example of Show Power-Management Output
Planning and Implementing a PoE
Configuration
This section provides an overview of some considerations for planning a PoE
application. For additional information, refer to the ProCurve PoE Planning
and Implementation Guide.
Assigning PoE Ports to VLANs
If your network includes VLANs, you may want to assign various PoE-
configured ports to specific VLANs. For example, if you are using PoE
telephones in your network, you may want to assign ports used for telephone
access to a VLAN reserved for telephone traffic.
Applying Security Features to PoE Configurations
You can utilize security features built into the switch to control device or user
access to the network through PoE ports in the same way as non-PoE ports.
11-14
