HP ProLiant DL360 G7 User Manual

Operations 24
c.
Lift the assembly to unseat the PCI riser boards, and then remove the assembly.
Install the PCI riser board assembly
CAUTION: To prevent damage to the server or expansion boards, power down the server
and remove all AC power cords before removing or installing the PCI riser board assembly.
1. Align the PCI riser boards with the corresponding connectors on the system board, and then install
the assembly.
2. Tighten the four PCI riser board assembly thumbscrews.
3. Install the air baffle (on page 22).
4. If removed, install the BBWC battery pack or the FBWC capacitor pack ("Installing the BBWC
battery pack or the FBWC capacitor pack" on page 58).
5. Install the access panel (on page 21).
6. Slide the server into the rack.

HP ProLiant DL360 G7 Specifications

General

Storage	Up to 8 SFF SAS/SATA/SSD drives
Form Factor	1U Rack
Processor	Intel Xeon 5600 series
Memory	Up to 192GB DDR3
Network	Embedded NC382i Dual Port Multifunction Gigabit Server Adapter
Power Supply	Hot-plug redundant power supplies (460W, 750W, or 1200W)
Expansion Slots	2 x PCIe Gen2
RAID Controller	HP Smart Array P410i
Network Controller	HP NC382i Dual Port Multifunction Gigabit Server Adapter
Management	Integrated Lights-Out 3 (iLO 3)
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
