Setup 31
Item Description
8 NIC 4 connector
9 NIC 3 connector
10 NIC 2 connector
11 NIC 1 connector
12 USB connectors (2)
*This expansion slot provides 75 W of power to an adapter, with an additional 75 W of power supplied by external
power.
3.
Connect the power cord to the server.
4. Use the strain relief clip from the server hardware kit to secure the power cord.
5. Connect the power cord to the power source.
Powering up and configuring the server
To power up the server, press the Power On/Standby button.
While the server boots, RBSU and the ORCA utility are automatically configured to prepare the server for
operating system installation.
To configure these utilities manually:
• Press the F8 key when prompted during the array controller initialization to configure the array
controller using ORCA.
• Press the F9 key when prompted during the boot process to change the server settings using RBSU.
The system is set up by default for the English language.
For more information on the automatic configuration, refer to the HP ROM-Based Setup Utility User Guide
located on the Documentation CD.

HP ProLiant DL360 G7 Specifications

General

Storage	Up to 8 SFF SAS/SATA/SSD drives
Form Factor	1U Rack
Processor	Intel Xeon 5600 series
Memory	Up to 192GB DDR3
Network	Embedded NC382i Dual Port Multifunction Gigabit Server Adapter
Power Supply	Hot-plug redundant power supplies (460W, 750W, or 1200W)
Expansion Slots	2 x PCIe Gen2
RAID Controller	HP Smart Array P410i
Network Controller	HP NC382i Dual Port Multifunction Gigabit Server Adapter
Management	Integrated Lights-Out 3 (iLO 3)
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
