Racking the DTC 16xx family
4
Racking the DTC 16xx family
Included with your DTC is an accessories kit which contains the parts
necessary for mounting the DTC 16xx in a rack. HP recommends that
members of the DTC 16xx family are racked as illustrated below. Each DTC
16xx occupies one EIA unit. (DDPs and MDPs will occupy additional EIA
units.)
Note If your DTC 16xx is not to be installed in a rack, attach the four rubber feet and the
display code label to the underside of your DTC 16xx as shown below.
Mount the DTC 16xx at the front of a rack with the front panel facing out.
