Item Description Spare part number
Thermal pads (attach to middle frame under system board; not illustrated)
Thermal pad for use with the thermal module and processor 671549-001
Thermal pad for use with VCORE 671550-001
Thermal pad for use with VAXG 671551-001
Thermal pad for use with PCH/SB 671552-001
Thermal pad for use with memory modules 671553-001
Power supply, 180W, external (not illustrated) 613766-001
Mouse
USB, optical 596410-001
Wireless 625685-001
Hard drive cage (not illustrated) 671554-001
Hard drive rubber grommet (not illustrated) 663357-001
Optical drive dummy bezel (not illustrated) 671556-001
Optical drive bezel (not illustrated) 671557-001
Optical drive bracket (not illustrated) 671558-001
Label, rear I/O (NTSC/PAL) (not illustrated) 671592-001
Keyboards (not illustrated)
NOTE: For a detailed list of keyboards and country codes, see Sequential part number listing
on page 33.
Description Spare part number
USB, red 537924-xx1
USB 537924-xx1
USB, low cost 630886-xx1
Wireless 665719-xx1
USB, jade with Beats logo 655572-xx1
USB, jade 655571-xx1
32 Chapter 6 Illustrated parts catalog
