Stand
Description Spare part number
Stand 671591-001
The stand is secured with 8 screws.
To remove the stand:
1. Prepare the computer for disassembly (see
Preparing to Disassemble the Computer
on page 40).
2. Remove the rear cover (see
Rear Cover on page 41).
3. To keep the stand from binding the screws, position the computer with the front facing downward
and the stand not touching the surface.
4. Remove the 8 Phillips screws (4 from each side) (1) that secure the stand to the computer.
5. Pull the stand down slightly, and then lift it off the computer (2).
Figure 7-2 Removing the stand
To replace the stand, reverse the removal procedures.
42 Chapter 7 Removal and Replacement Procedures All-in One (AIO) Chassis
