TV Tuner Module
Description Spare part number
HP Digital TV Tuner Mini PCIe Card (includes TV tuner and hardware kit; non-BFR) 613990-001
HP Digital TV Tuner Mini PCIe Card (includes TV tuner and hardware kit; BFR) 621425-001
HP TV Tuner SW DVB-T Mini Card for use in EMEA 671566-001
The TV tuner module is secured with 2 screws and has 1 connected antenna.
Figure 7-29 TV tuner module location
To remove the TV tuner module:
1. Prepare the computer for disassembly (see
Preparing to Disassemble the Computer
on page 40).
2. Remove the rear cover (see
Rear Cover on page 41).
3. Remove the system board cover (see
System Board Cover on page 60).
4. Disconnect the antenna cable from the module (1).
64 Chapter 7 Removal and Replacement Procedures All-in One (AIO) Chassis
