HP Z2 Mini G3 User Manual

HP Linux driver discs
Driver ISO images that support proper use and behavior of some Linux OSes on HP Workstations may be
available on the HP website. Such images include tested drivers that augment and/or replace those found in
RHEL, SLED, Ubuntu, or other OSes. Each image is specic to a particular Linux OS release.
These images also can be downloaded using the following steps:
1. Go to http://www.hp.com/support/workstation_swdrivers.
2. Select your workstation model.
3. Select the desired operating system.
4. Select the Obtain Software link for the appropriate package (typically the most recent revision).
5. Click I Accept to accept the terms of the license agreement.
6. Download the software ISO image and burn it to a high-quality blank DVD-R, DVD+R, DVD-R DL, or DVD
+R DL disc using an external optical drive with DVD writer capability. Do not use rewritable discs such as
CD±RW, DVD±RW, double-layer DVD±RW, or BD-RE (rewritable Blu-ray) discs; they are not compatible
with HP Recovery Manager software. A compatible external optical drive may be purchased from HP.
This disc is your HP driver disc.
Setting up Red Hat Enterprise Linux (RHEL)
HP Z series Workstations are certied and supported on RHEL streams appropriate to the hardware
technology.
●
For details of RHEL support for a particular platform, see the Linux Hardware Matrix for HP Workstations
at http://www.hp.com/support/linux_hardware_matrix.
●
For information about Red Hat certications on HP Workstations, go to https://hardware.redhat.com.
HP driver disc
Recent versions of Red Hat Linux typically require only driver updates with minor xes to support HP
Workstations. These releases can usually be supported with the appropriate driver USB ash drive or optical
disc from the HP website, which can be used as a post-installation utility for the standard Red Hat Linux
install. For more information, see HP Linux driver discs on page 34.
After you complete the standard Red Hat install and restart the system, a Red Hat rst-boot utility runs. After
you specify a number of settings (such as the security level, time and date, ‘root’ password, and user
accounts), the utility lets you load an additional USB ash drive or optical disc.
The driver media is used during this phase. All content added by HP is in the /HP directory on the media. You
can use it to build your own image or to browse the HP content.
Please see /HP directory on the media for any last-minute README pointers for elements on the disc.
34 Chapter 6 Setting up Linux

HP Z2 Mini G3 Specifications

General

Tcase	71 °C
Bus type	DMI3
Stepping	R0
Processor cache	8 MB
Processor cores	4
Processor model	i7-6700
System bus rate	8 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-6700 Desktop series
Processor socket	LGA 1151 (Socket H4)
Processor threads	8
Processor codename	Skylake
Processor frequency	3.4 GHz
Processor cache type	Smart Cache
Processor lithography	14 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	4 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	2x8, 1x8+2x4, 1x16
Thermal Design Power (TDP)	65 W
Number of processors installed	1
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3L-SDRAM, DDR4-SDRAM
Memory voltage supported by processor	1.35 V
Memory clock speeds supported by processor	1333, 1600, 1866, 2133 MHz
Memory bandwidth supported by processor (max)	34.1 GB/s
Maximum internal memory supported by processor	64 GB
Product type	Workstation
Motherboard chipset	Intel® C236
Non-ECC	Yes
Memory slots	2x SO-DIMM
Internal memory	16 GB
Memory channels	Dual-channel
Memory clock speed	2400 MHz
Internal memory type	DDR4-SDRAM
Maximum internal memory	32 GB
Memory layout (slots x size)	2 x 8 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	PCI Express
Storage media	SSD
Total storage capacity	256 GB
On-board graphics card ID	1912
Discrete graphics card model	NVIDIA® Quadro® M620
On-board graphics card model	Intel® HD Graphics 530
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.74 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	350 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1150 MHz
Number of displays supported (on-board graphics)	3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Power supply	135 W
USB 2.0 ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	2
Sustainability certificates	ENERGY STAR
Chassis type	Small Desktop
Product color	Black
Country of origin	China
Scalability	1S
Processor code	SR2BT
Processor ARK ID	88196
Processor package size	37.5 x 37.5 mm
Supported instruction sets	SSE4.1, AVX 2.0, SSE4.2
Thermal solution specification	PCG 2015C
Intel Secure Key Technology version	1.00

Weight and Dimensions

Depth	216 mm
Width	2040 mm
Weight	58 g
