HP Z230 User Manual

Diagnostic codes and errors
This section presents information about diagnostic LED codes, LED color definitions, and POST error
messages to help you troubleshoot problems.
Diagnostic LED and audible (beep) codes
This section describes the front panel LED error and operation codes as well as the audible codes
that might occur before or during the POST.
Activity Possible cause Recommended action
Blue Power LED
*
on. No
beeps.
Computer on.
N/A
Blue Power LED
*
blinks
every two seconds.
*
No
beeps.
Computer in Sleep
mode (S3-Suspend to
RAM). Select models
only.
Blue Power LED
*
is off.
*
No beeps.
Computer in Hibernate
mode (S4-Suspend to
disk) or system is off
(S5).
Blue Power LED
*
blinks
three times*, once per
second.
*
No beeps.
Computer in Sleep
mode (S3-Suspend to
RAM). Select models
only.
Blue Power LED
*
blinks
four times*, once per
second.
*
No beeps.
Computer in Hibernate
mode (S4-Suspend to
disk).
User-selectable for details.
For the following LED activity and beeps, the beeps are heard through the chassis speaker. Blinks and beeps repeat for
five cycles, after which, only the blinks continue to repeat.
Red Power LED blinks
two times, once every
second, followed by a
two-second pause. Two
beeps.
CPU thermal protection
activated by either of
the following methods:
●
A fan might be
blocked or not
turning.
●
The heatsink and
fan assembly is not
properly attached
to the CPU.
CAUTION: Internal components might be powered even when
the computer is off. To prevent damage, disconnect the
computer power cord before you remove a component.
1. Make sure that the computer air vents are not blocked and
the cooling fan is running.
2. Open the access panel, press power button, and verify that
the CPU fan is spinning. If the CPU fan is not spinning,
make sure the fan cable is plugged into the computer board
header. Make sure the fan is fully and properly seated or
installed.
3. If fan is plugged in and seated properly, but is not spinning,
the problem might be in the CPU fan. Contact HP for
assistance.
4. Verify that the fan assembly is properly attached. If
problems persist, there might be a problem with the CPU
heatsink. Contact HP for assistance.
Red Power LED blinks
three times, once every
second, followed by a
two-second pause. Three
beeps.
CPU not installed (not
an indicator of bad
CPU).
1. Verify that the CPU is present.
2. Reseat the CPU.
92 Chapter 4 Diagnostics and troubleshooting

HP Z230 Specifications

General

Product type	Workstation
Motherboard chipset	Intel® C226
ECC	Yes
Memory slots	4x DIMM
Internal memory	4 GB
Memory channels	Dual-channel
Memory clock speed	1600 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	32 GB
Memory layout (slots x size)	1 x 4 GB
Chassis type	Desktop
Product color	Black
Country of origin	China
Placement supported	Vertical
Number of 3.5\" bays	1
Water cooling system	No
HDD speed	7200 RPM
RAID levels	0, 1
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi
Total storage capacity	500 GB
PS/2 ports quantity	2
DisplayPorts quantity	3
Serial ports quantity	-
USB 2.0 ports quantity	6
VGA (D-Sub) ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
Ethernet LAN data rates	10, 100, 1000 Mbit/s
On-board graphics card ID	0x412
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 4600
Maximum on-board graphics card memory	1.74 GB
On-board graphics card base frequency	350 MHz
On-board graphics card DirectX version	11.1
On-board graphics card dynamic frequency (max)	1150 MHz
Power supply	240 W
Tcase	72.72 °C
Bus type	DMI2
Stepping	C0
Processor cache	6 MB
Processor model	i5-4570
System bus rate	5 GT/s
Processor family	Intel® Core™ i5
Processor socket	LGA 1150 (Socket H3)
Processor codename	Haswell
Processor frequency	3.2 GHz
Processor cache type	Smart Cache
Processor lithography	28 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.6 GHz
Processor operating modes	64-bit
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	84 W
Maximum number of PCI Express lanes	16
Memory clock speeds supported by processor	1333, 1600 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Operating system installed	Windows 7 Professional
Scalability	1S
Processor code	SR14E
Processor ARK ID	75043
Intel TSX-NI version	0.00
Processor package size	37.5 x 37.5 mm
Graphics & IMC lithography	22 nm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal solution specification	PCG 2013D
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	384 mm
Width	337 mm
Height	100 mm
Weight	7200 g
