HP Z230 User Manual

Designator Silk screen Component/Description
P160 SATAPWR1 HDD power (black)
XBT1 XBT1 BAT Battery holder
XMM1 - XMM4 XMM1 - XMM4
DIMM1 - DIMM4
Memory slots
XU1 XU1 CPU socket
Tower workstation system board designators
Designator Silk screen Component
E15 E15 Crisis recovery header/jumper
E49 E49 Clear password header/jumper
J9 J9 RJ/USB LAN/DUAL USB
J10 J10 QUAD USB Dual USB3.0/Dual USB2.0
J31 SLOT1 PCIe2 x4(1) PCIe2 x4(1) connector
J33 SLOT3 PCIe2 x1 PCIe2 x1 connector
J34 SLOT5 PCI 32/33 PCI 32/33 connector
J41 SLOT2 PCIe3 x16 PCIe3 x16 connector
J42 SLOT4 PCIe2 x16(4) PCIe2 x16(4) connector
J64 DP Dual-Mode DisplayPort connector
J65 DVI DVI-I connector
J68 J68 PS2 Stacked keyboard/mouse connector
J83 J83 Triple stacked audio jacks
J86 J86 Slot2 PCIe x16 retention clip
MTG1-MTG10 N/A Mounting holes
P1 P1 Power supply connector (18-pin)
P3 P3 CPU PWR CPU power connector (4-pin)
P5 P5 Power button/HDD LED/Power LED switch/Side
access panel sensor/Temperature header
P6 SPKR Speaker
P8 CPU FAN CPU fan header
P9 P9 Front fan header
P11 CHF Fan Rear system fan
P23 P23 FRONT AUD Front audio header
P24 P24 FRONT USB Front panel USB header
P26 P26 FRONT USB3 Front panel USB3 header (blue)
Tower workstation system board designators 115

HP Z230 Specifications

General

Product type	Workstation
Motherboard chipset	Intel® C226
ECC	Yes
Memory slots	4x DIMM
Internal memory	4 GB
Memory channels	Dual-channel
Memory clock speed	1600 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	32 GB
Memory layout (slots x size)	1 x 4 GB
Chassis type	Desktop
Product color	Black
Country of origin	China
Placement supported	Vertical
Number of 3.5\" bays	1
Water cooling system	No
HDD speed	7200 RPM
RAID levels	0, 1
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi
Total storage capacity	500 GB
PS/2 ports quantity	2
DisplayPorts quantity	3
Serial ports quantity	-
USB 2.0 ports quantity	6
VGA (D-Sub) ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
Ethernet LAN data rates	10, 100, 1000 Mbit/s
On-board graphics card ID	0x412
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 4600
Maximum on-board graphics card memory	1.74 GB
On-board graphics card base frequency	350 MHz
On-board graphics card DirectX version	11.1
On-board graphics card dynamic frequency (max)	1150 MHz
Power supply	240 W
Tcase	72.72 °C
Bus type	DMI2
Stepping	C0
Processor cache	6 MB
Processor model	i5-4570
System bus rate	5 GT/s
Processor family	Intel® Core™ i5
Processor socket	LGA 1150 (Socket H3)
Processor codename	Haswell
Processor frequency	3.2 GHz
Processor cache type	Smart Cache
Processor lithography	28 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.6 GHz
Processor operating modes	64-bit
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	84 W
Maximum number of PCI Express lanes	16
Memory clock speeds supported by processor	1333, 1600 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Operating system installed	Windows 7 Professional
Scalability	1S
Processor code	SR14E
Processor ARK ID	75043
Intel TSX-NI version	0.00
Processor package size	37.5 x 37.5 mm
Graphics & IMC lithography	22 nm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal solution specification	PCG 2013D
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	384 mm
Width	337 mm
Height	100 mm
Weight	7200 g
