HP Z230 User Manual

Clearing and resetting the CMOS
This section describes the steps necessary to successfully clear and reset the CMOS. The CMOS of
the computer stores password information and information about the computer configuration.
Using the CMOS button to reset CMOS
To clear CMOS using the Clear CMOS button, use the following procedure:
WARNING! To reduce the risk of personal injury from electric shock and hot surfaces, disconnect
the power cord from the wall outlet and allow the internal system components to cool before touching
them.
CAUTION: When the computer is plugged in, the power supply has voltage applied to the system
board, even when the computer is powered off. Failure to disconnect the power cord can result in
damage to the system.
Static electricity can damage the electronic components of the computer or optional equipment.
Before beginning these procedures, be sure that you are discharged of static electricity by briefly
touching a grounded metal object.
1. Back up your computer CMOS settings, run Computer Setup (f10) Utility, and select File > Save
to Disk.
CAUTION: Pressing the Clear CMOS button resets CMOS values to factory defaults and
erases customized information, including asset numbers and special settings.
2. Shut down the operating system, power off the computer and external devices, and disconnect
peripheral devices.
3. Disconnect the AC power cord from the power outlet.
NOTE: The CMOS button does not clear CMOS if the power cord is connected.
4. Open the workstation.
5. Locate, press, and hold the CMOS button for five seconds.
For assistance locating the CMOS button and other system board components, see the system
board layout in
Hardware overview on page 1.
6. Close the workstation, reconnect external devices, connect the power cord and turn on the
workstation.
7. The system boots to an f1 prompt and displays a message that the date/time has changed and
that system options have changed.
8. Press f1. The system shuts down for three seconds and then powers on again.
9. Use Computer Setup (f10) Utility to reset the date and time.
102 Chapter 5 Configuring password security and resetting CMOS

HP Z230 Specifications

General

Product type	Workstation
Motherboard chipset	Intel® C226
ECC	Yes
Memory slots	4x DIMM
Internal memory	4 GB
Memory channels	Dual-channel
Memory clock speed	1600 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	32 GB
Memory layout (slots x size)	1 x 4 GB
Chassis type	Desktop
Product color	Black
Country of origin	China
Placement supported	Vertical
Number of 3.5\" bays	1
Water cooling system	No
HDD speed	7200 RPM
RAID levels	0, 1
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi
Total storage capacity	500 GB
PS/2 ports quantity	2
DisplayPorts quantity	3
Serial ports quantity	-
USB 2.0 ports quantity	6
VGA (D-Sub) ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
Ethernet LAN data rates	10, 100, 1000 Mbit/s
On-board graphics card ID	0x412
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 4600
Maximum on-board graphics card memory	1.74 GB
On-board graphics card base frequency	350 MHz
On-board graphics card DirectX version	11.1
On-board graphics card dynamic frequency (max)	1150 MHz
Power supply	240 W
Tcase	72.72 °C
Bus type	DMI2
Stepping	C0
Processor cache	6 MB
Processor model	i5-4570
System bus rate	5 GT/s
Processor family	Intel® Core™ i5
Processor socket	LGA 1150 (Socket H3)
Processor codename	Haswell
Processor frequency	3.2 GHz
Processor cache type	Smart Cache
Processor lithography	28 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.6 GHz
Processor operating modes	64-bit
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	84 W
Maximum number of PCI Express lanes	16
Memory clock speeds supported by processor	1333, 1600 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Operating system installed	Windows 7 Professional
Scalability	1S
Processor code	SR14E
Processor ARK ID	75043
Intel TSX-NI version	0.00
Processor package size	37.5 x 37.5 mm
Graphics & IMC lithography	22 nm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal solution specification	PCG 2013D
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	384 mm
Width	337 mm
Height	100 mm
Weight	7200 g
