HP Z230 User Manual

RAID hard drive maximum and associated storage controller
options
This section lists the maximum number of hard drives supported on HP workstations according to
RAID configuration and storage controller options.
NOTE: This section applies to internal workstation configurations that do not use add-in cards and
external enclosures.
Maximum hard drives allowed
Hard drives Storage controllers
SATA Onboard
8.5 mm
(3.5 in)
6.3 mm
(2.5 in)
RST
SFF 2 2 Yes
Tower 3 3 Yes
Supported RAID configurations
The following RAID configurations are supported:
RAID configuration details
Configuration Description Controllers
RAID 0
Integrated striped disk
array
●
Requires a minimum of two drives.
●
Provides improved I/O performance.
●
Provides no fault tolerance.
●
Loses all data if any disk in the array fails.
●
Increases disk performance.
Intel with RST
RAID 1
Mirrored disk array
●
Supports a minimum of two drives.
●
Provides 100% redundancy: all data from one
drive is duplicated on a second drive.
●
Recovers from a single-drive failure.
●
Serves as a good entry-level redundant system.
Intel with RST
RAID 5
Striped disk array with
distributed parity
●
Supports three or more drives.
●
Provides fault tolerance and I/O performance
improvement, especially for write-biased
applications.
●
Retains all data if a single drive fails but
performance is compromised until the failed
drive is replaced and the array rebuilt.
Intel with RST
RAID hard drive maximum and associated storage controller options 109

HP Z230 Specifications

General

Product type	Workstation
Motherboard chipset	Intel® C226
ECC	Yes
Memory slots	4x DIMM
Internal memory	4 GB
Memory channels	Dual-channel
Memory clock speed	1600 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	32 GB
Memory layout (slots x size)	1 x 4 GB
Chassis type	Desktop
Product color	Black
Country of origin	China
Placement supported	Vertical
Number of 3.5\" bays	1
Water cooling system	No
HDD speed	7200 RPM
RAID levels	0, 1
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi
Total storage capacity	500 GB
PS/2 ports quantity	2
DisplayPorts quantity	3
Serial ports quantity	-
USB 2.0 ports quantity	6
VGA (D-Sub) ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
Ethernet LAN data rates	10, 100, 1000 Mbit/s
On-board graphics card ID	0x412
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 4600
Maximum on-board graphics card memory	1.74 GB
On-board graphics card base frequency	350 MHz
On-board graphics card DirectX version	11.1
On-board graphics card dynamic frequency (max)	1150 MHz
Power supply	240 W
Tcase	72.72 °C
Bus type	DMI2
Stepping	C0
Processor cache	6 MB
Processor model	i5-4570
System bus rate	5 GT/s
Processor family	Intel® Core™ i5
Processor socket	LGA 1150 (Socket H3)
Processor codename	Haswell
Processor frequency	3.2 GHz
Processor cache type	Smart Cache
Processor lithography	28 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.6 GHz
Processor operating modes	64-bit
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	84 W
Maximum number of PCI Express lanes	16
Memory clock speeds supported by processor	1333, 1600 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Operating system installed	Windows 7 Professional
Scalability	1S
Processor code	SR14E
Processor ARK ID	75043
Intel TSX-NI version	0.00
Processor package size	37.5 x 37.5 mm
Graphics & IMC lithography	22 nm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal solution specification	PCG 2013D
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	384 mm
Width	337 mm
Height	100 mm
Weight	7200 g
