HP Z4 G4 User Manual

●
If you have installed an operating system other than the factory-installed operating system, check to be
sure that it is supported on the system.
●
If the system has multiple video sources installed and a single monitor, the monitor must be plugged
into the monitor connector on the source selected as the primary monitor adapter. During boot,
the other monitor connectors are disabled and if the monitor is connected into these ports, the monitor
will not function. You can select which source will be the default monitor source in Computer Setup.
CAUTION: When the computer is plugged into an AC power source, there is always voltage applied to
the system board. You must disconnect the power cord from the power source before opening the computer
to prevent system board or component damage.
Solving general problems
You may be able to easily resolve the general problems described in this section. If a problem persists and you
are unable to resolve it yourself or if you feel uncomfortable about performing the operation, contact an
authorized dealer or reseller.
WARNING! When the computer is plugged into an AC power source, voltage is always applied to the system
board. To reduce the risk of personal injury from electrical shock and/or hot surfaces, be sure to disconnect
the power cord from the AC outlet and allow the internal system components to cool before touching.
Cannot access the Computer Setup (F10) Utility when booting the computer.
Cause Solution
The Computer Setup (F10) Utility is set to “fast boot” causing
the F10 access screen to display too briey when booting
the computer.
Before turning on the computer, press and hold F10. Turn on
the computer and continue to hold F10 until the Computer Setup
(F10) Utility is displayed.
- or –
Follow the Windows instructions for rebooting the computer into
the Computer Setup (F10) Utility.
Computer appears locked up and will not turn o when the power button is pressed.
Cause Solution
Software control of the power switch is not functional. 1. Press and hold the power button for at least four seconds
until the computer turns o.
2. Disconnect the power cord from the AC outlet.
Computer will not respond to keyboard or mouse.
Cause Solution
Computer is in Sleep state. To resume from Sleep state, press the power button.
CAUTION: When attempting to resume from Sleep state, do not
hold down the power button for more than four seconds.
Otherwise, the computer will shut down and you will lose any
unsaved data.
System has locked up. Restart computer.
40 Chapter 6 Troubleshooting without diagnostics

HP Z4 G4 Specifications

General

Tcase	65 °C
Bus type	QPI
Stepping	U0
Processor cache	8.25 MB
Processor cores	6
Processor model	W-2133
System bus rate	0 GT/s
Processor socket	LGA 2066 (Socket R4)
Processor threads	12
Processor codename	Skylake
Processor frequency	3.6 GHz
Processor lithography	14 nm
Processor manufacturer	Intel
PCI Express slots version	3.0
Processor boost frequency	3.9 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
PCI Express configurations	1x16, 1x4, 1x8
Thermal Design Power (TDP)	140 W
Number of processors installed	1
Maximum number of PCI Express lanes	48
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	1600, 1866, 2133, 2400, 2666 MHz
Memory bandwidth supported by processor (max)	85.3 GB/s
Maximum internal memory supported by processor	512 GB
Operating system installed	Windows 10 Pro for Workstations
Memory slots	8x DIMM
Internal memory	16 GB
Memory channels	Quad-channel
Memory clock speed	2666 MHz
Maximum internal memory	256 GB
Memory layout (slots x size)	2 x 8 GB
HDD speed	7200 RPM
RAID levels	0, 1, 5, 10
HDD capacity	1000 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
HDD interface	SATA
SSD interface	PCI Express
Storage media	HDD+SSD
Optical drive type	DVD-RW
Card reader integrated	No
Total storage capacity	1256 GB
Discrete graphics card model	Not available
Power supply	1000 W
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	10
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	2
Sustainability certificates	ENERGY STAR
Chassis type	Tower
Product color	Black
Country of origin	China
Intel® vPro™ Platform Eligibility	-
Audio chip	Realtek HD ALC221
Product type	Workstation
Motherboard chipset	Intel® C422
Scalability	1S
Processor code	SR3LL
Processor ARK ID	125040
Processor package size	45 x 52.5 mm
Supported instruction sets	AVX, AVX 2.0, AVX-512, SSE4.2
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	445 mm
Width	169 mm
Height	386 mm
Weight	10200 g
