HP Z4 G4 User Manual

9 Using HP PC Hardware Diagnostics
Using HP PC Hardware Diagnostics Windows
HP PC Hardware Diagnostics Windows is a Windows-based utility that allows you to run diagnostic tests to
determine whether the computer hardware is functioning properly. The tool runs within the Windows
operating system in order to diagnose hardware failures.
If HP PC Hardware Diagnostics Windows is not installed on your computer, rst you must download and install
it. To download HP PC Hardware Diagnostics Windows, see Downloading HP PC Hardware Diagnostics
Windows on page 76.
After HP PC Hardware Diagnostics Windows is installed, follow these steps to access it from HP Help and
Support or HP Support Assistant.
1. To access HP PC Hardware Diagnostics Windows from HP Help and Support:
a. Select the Start button, and then select HP Help and Support.
b. Right-click HP PC Hardware Diagnostics Windows, select More, and then select Run as
administrator.
– or –
To access HP PC Hardware Diagnostics Windows from HP Support Assistant:
a. Type support in the taskbar search box, and then select the HP Support Assistant app.
– or –
Select the question mark icon in the taskbar.
b. Select Troubleshooting and xes.
c. Select Diagnostics, and then select HP PC Hardware Diagnostics Windows.
2. When the tool opens, select the type of diagnostic test you want to run, and then follow the on-screen
instructions.
NOTE: If you need to stop a diagnostic test at any time, select Cancel.
3. When HP PC Hardware Diagnostics Windows detects a failure that requires hardware replacement, a 24-
digit Failure ID code is generated. For assistance in correcting the problem, contact support, and then
provide the Failure ID code.
Downloading HP PC Hardware Diagnostics Windows
●
The HP PC Hardware Diagnostics Windows download instructions are provided in English only.
●
You must use a Windows computer to download this tool because only .exe les are provided.
76 Chapter 9 Using HP PC Hardware Diagnostics

HP Z4 G4 Specifications

General

Tcase	65 °C
Bus type	QPI
Stepping	U0
Processor cache	8.25 MB
Processor cores	6
Processor model	W-2133
System bus rate	0 GT/s
Processor socket	LGA 2066 (Socket R4)
Processor threads	12
Processor codename	Skylake
Processor frequency	3.6 GHz
Processor lithography	14 nm
Processor manufacturer	Intel
PCI Express slots version	3.0
Processor boost frequency	3.9 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
PCI Express configurations	1x16, 1x4, 1x8
Thermal Design Power (TDP)	140 W
Number of processors installed	1
Maximum number of PCI Express lanes	48
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	1600, 1866, 2133, 2400, 2666 MHz
Memory bandwidth supported by processor (max)	85.3 GB/s
Maximum internal memory supported by processor	512 GB
Operating system installed	Windows 10 Pro for Workstations
Memory slots	8x DIMM
Internal memory	16 GB
Memory channels	Quad-channel
Memory clock speed	2666 MHz
Maximum internal memory	256 GB
Memory layout (slots x size)	2 x 8 GB
HDD speed	7200 RPM
RAID levels	0, 1, 5, 10
HDD capacity	1000 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
HDD interface	SATA
SSD interface	PCI Express
Storage media	HDD+SSD
Optical drive type	DVD-RW
Card reader integrated	No
Total storage capacity	1256 GB
Discrete graphics card model	Not available
Power supply	1000 W
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	10
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	2
Sustainability certificates	ENERGY STAR
Chassis type	Tower
Product color	Black
Country of origin	China
Intel® vPro™ Platform Eligibility	-
Audio chip	Realtek HD ALC221
Product type	Workstation
Motherboard chipset	Intel® C422
Scalability	1S
Processor code	SR3LL
Processor ARK ID	125040
Processor package size	45 x 52.5 mm
Supported instruction sets	AVX, AVX 2.0, AVX-512, SSE4.2
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	445 mm
Width	169 mm
Height	386 mm
Weight	10200 g
