Saving and printing information in HP Vision Diagnostics
You can save the information displayed in the HP Vision Diagnostics Survey, History and Errors tabs
to a diskette or a USB flash drive. You can not save to the hard drive. The system will automatically
create an html file that has the same appearance as the information displayed on the screen.
1. Insert a diskette or USB flash drive if running HP Vision Diagnostics from CD.
2. Click Save in the bottom on any of the Survey, History or Errors tabs. All three log files will be saved
regardless of from which tab the Save button was clicked.
3. Select the drive onto which you will save the log files and click the Save button. Three html files
will be saved to the inserted diskette or USB flash drive.
NOTE: Do not remove the diskette or USB key until you see a message indicating that the html
files have been written to the media.
4. Print the desired information from the storage device used to save it.
NOTE: To exit HP Vision Diagnostics, click the Exit Diagnostics button at the bottom of the
screen. Be sure to remove the USB flash drive or CD from the optical drive.
Diagnostic codes and errors
This section presents information about diagnostic LED codes, LED color definitions, and POST error
messages to help you troubleshoot problems.
Diagnostic LED and audible (beep) codes
This section describes the front panel LED error and operation codes as well as the audible codes that
might occur before or during the POST.
Table 6-8 Diagnostic lights and audible codes
Activity Possible cause Recommended action
Blue Power LED
*
on. No
beeps.
Workstation on.
N/A
Blue Power LED
*
blinks
every two seconds.
*
No
beeps.
Workstation in Sleep mode
(S3-Suspend to RAM).
Select models only.
Blue Power LED
*
is off.
*
No
beeps.
Workstation in Hibernate
mode (S4-Suspend to disk)
or off state (S5).
Blue Power LED
*
blinks
three times*, once per
second.
*
No beeps.
Workstation in Sleep mode
(S3-Suspend to RAM).
Select models only.
Blue Power LED
*
blinks four
times*, once per second.
*
No
beeps.
Workstation in Hibernate
mode (S4-Suspend to disk).
*User-selectable. See The Computer Setup (F10) Utility
menu on page 33 for details.
For the following LED activity and beeps, the beeps are heard through the chassis speaker. Blinks and beeps repeat for 5 cycles, after
which, only the blinks continue to repeat.
ENWW Diagnostic codes and errors 165
