HP ZBook 14U G5 User Manual

Item Component Spare part number
(1) Display assemblies are spared at the subcomponent level only. For display assembly
spare part information, see Display assembly subcomponents on page 28.
not spared as whole hinge-up
(2) Touch not spared as whole hinge-up
(3) Keyboard (see Keyboard on page 45)
For a list of keyboard country codes, see Keyboard on page 45.
Without a backlight L15542-xx1
With a backlight L15540-xx1
With a backlight, privacy L15541-xx1
(4) Top cover L17825-001
(5) RJ-45 board with bracket L19422-001
(6) TouchPad
For use in models without an NFC module L15544-001
For use in models with an NFC module L19419-001
(7) TouchPad button board L17826-001
(8) RTC battery L17255-001
(9) Power button board L14374-001
(10) USB board L14380-001
(11) USB board bracket L14380-001
(12) Fingerprint reader assembly (includes cable) L15537-001
(13) NFC module (includes antenna and TouchPad foam) L14385-001
(14) Speakers (includes cable) L13684-001
(15) Smart card reader board (includes cable) L18312-001
(16) System board (includes processor and replacement thermal material, see System board on page 67)
All system boards use the following part numbers:
xxxxxx-001: Non-Windows operating systems
xxxxxx-601: Windows operating system
For use in models with discrete graphics memory
Intel i7-8650U processor L16126-xx1
Intel i7-8550U processor L16124-xx1
Intel i5-8350U processor L16121-xx1
Intel i5-8250U processor L16119-xx1
Intel i5-7200U processor L16117-xx1
For use in models with UMA graphics memory
Intel i7-8650U processor L15522-001
Intel i7-8550U processor L15520-001
Computer major components 25

HP ZBook 14U G5 Specifications

General

Form factor	Clamshell
Product type	Mobile workstation
Product color	Silver
Country of origin	China
Market positioning	Business
LED backlight	Yes
Display diagonal	14 \
Display brightness	220 cd/m²
Native aspect ratio	16:9
sRGB coverage (typical)	67 %
Memory slots	1x SO-DIMM
Internal memory	8 GB
Memory clock speed	2400 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR4-SDRAM
Maximum internal memory	32 GB
Memory layout (slots x size)	1 x 8 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	PCI Express
Storage media	SSD
SSD memory type	TLC
Total storage capacity	256 GB
Compatible memory cards	SD, SDHC, SDXC
Number of SSDs installed	1
Discrete GPU manufacturer	AMD
On-board graphics card ID	0x5917
Discrete graphics card model	AMD Radeon Pro WX 3100
On-board graphics card model	Intel® UHD Graphics 620
Discrete graphics card memory	2 GB
Discrete graphics memory type	GDDR5
On-board graphics card family	Intel® UHD Graphics
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	300 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1100 MHz
Number of built-in speakers	2
Front camera HD type	HD
Front camera signal format	720p
Antenna type	-
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	4.2
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
HDMI version	1.4
Charging port type	DC-in jack
USB 2.0 ports quantity	0
Pointing device	Clickpad
Operating system architecture	64-bit
Sustainability certificates	ENERGY STAR
AC adapter power	65 W
Battery capacity	50 Wh
Number of battery cells	3
HP speaker type	HP Dual Speakers
Bus type	OPI
Stepping	Y0
Tjunction	100 °C
Processor cache	6 MB
Processor cores	4
System bus rate	4 GT/s
Processor family	Intel® Core™ i5
Processor socket	BGA 1356
Processor threads	8
Processor codename	Kaby Lake R
Configurable TDP-up	25 W
Processor frequency	1.6 GHz
Processor cache type	L3
Configurable TDP-down	10 W
Processor lithography	14 nm
Processor manufacturer	Intel
PCI Express slots version	3.0
Processor boost frequency	3.4 GHz
PCI Express configurations	1x2+2x1, 1x4, 2x2, 4x1
Thermal Design Power (TDP)	15 W
Configurable TDP-up frequency	1.8 GHz
Configurable TDP-down frequency	0.8 GHz
Maximum number of PCI Express lanes	12
Processor code	SR3LA
Processor ARK ID	124967
Processor package size	42 X 24 mm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Intel Identity Protection Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00

Weight and Dimensions

Depth	234.3 mm
Width	326 mm
Height	17.9 mm
Weight	1480 g
