HP ZBook 14U G5 User Manual

Item Component Spare part number
Intel i5-8350U processor L15518-001
Intel i5-8250U processor L15516-001
Intel i5-7300U processor L15523-001
Intel i5-7200U processor L15514-001
(17) Fan L22306-001
Heat sink
(18) For use in models with discrete graphics memory L14373-001
(19) For use in models with UMA graphics memory L14372-001
(20) Memory module (DDR-2400)
4-GB 820569-001
8-GB 820570-001
16-GB 820571-001
(21) WLAN/Bluetooth combo card
Realtek RTL8822BE 802.11ac 2x2 Wi-Fi + Bluetooth 4.2 Combo Adapter 915623-001
Intel Dual band wireless-AC 8265 802.11AC 2x2 WiFi + Bluetooth 4.2 Combo Adaptor
(vPro)
851592-001
Intel Dual band wireless-AC 8265 802.11AC 2x2 WiFi + Bluetooth 4.2 Combo Adaptor
(non-vPro)
851594-001
(22) WWAN module
LTE CAT4: Huawei HP lt4132, LTE/HSPA+ w/GPS 845710-003
LTE CAT9: Fibocom Intel XMM 7360 LTE-Advanced 917823-001
(23) Solid-state drive (SSD)
1 TB, PCIe, Gen3×4, NVMe, TLC L17246-001
1 TB, PCIe, Gen3×4, NVMe, SS, MLC L17848-001
512 GB, PCIe, Gen3×4, SS, TLC L17852-001
512 GB, PCIe, Gen3×4, SS, MLC L17851-001
512 GB, PCIe, Gen3×4, Self-encrypting drive (SED), Opal 2, TLC L17250-001
512 GB, SATA-3, FIPS-140–2, TLC L17249-001
256 GB, PCIe, Gen3x4, SS, NVMe, TLC L17247-001
256 GB, PCIe, Gen3x4, TLC, Opal 2, Self-encrypting drive (SED) L17850-001
256 GB, PCIe, Gen3x4, SS, NVMe, MLC L17849-001
128 GB, SATA-3, TLC L17847-001
(24) Battery (3 cell, 50 WHr, 4.33 Ah) 933321-855
(25) Bottom cover L15536-001
26 Chapter 3 Illustrated parts catalog

HP ZBook 14U G5 Specifications

General

Form factor	Clamshell
Product type	Mobile workstation
Product color	Silver
Country of origin	China
Market positioning	Business
LED backlight	Yes
Display diagonal	14 \
Display brightness	220 cd/m²
Native aspect ratio	16:9
sRGB coverage (typical)	67 %
Memory slots	1x SO-DIMM
Internal memory	8 GB
Memory clock speed	2400 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR4-SDRAM
Maximum internal memory	32 GB
Memory layout (slots x size)	1 x 8 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	PCI Express
Storage media	SSD
SSD memory type	TLC
Total storage capacity	256 GB
Compatible memory cards	SD, SDHC, SDXC
Number of SSDs installed	1
Discrete GPU manufacturer	AMD
On-board graphics card ID	0x5917
Discrete graphics card model	AMD Radeon Pro WX 3100
On-board graphics card model	Intel® UHD Graphics 620
Discrete graphics card memory	2 GB
Discrete graphics memory type	GDDR5
On-board graphics card family	Intel® UHD Graphics
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	300 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1100 MHz
Number of built-in speakers	2
Front camera HD type	HD
Front camera signal format	720p
Antenna type	-
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	4.2
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
HDMI version	1.4
Charging port type	DC-in jack
USB 2.0 ports quantity	0
Pointing device	Clickpad
Operating system architecture	64-bit
Sustainability certificates	ENERGY STAR
AC adapter power	65 W
Battery capacity	50 Wh
Number of battery cells	3
HP speaker type	HP Dual Speakers
Bus type	OPI
Stepping	Y0
Tjunction	100 °C
Processor cache	6 MB
Processor cores	4
System bus rate	4 GT/s
Processor family	Intel® Core™ i5
Processor socket	BGA 1356
Processor threads	8
Processor codename	Kaby Lake R
Configurable TDP-up	25 W
Processor frequency	1.6 GHz
Processor cache type	L3
Configurable TDP-down	10 W
Processor lithography	14 nm
Processor manufacturer	Intel
PCI Express slots version	3.0
Processor boost frequency	3.4 GHz
PCI Express configurations	1x2+2x1, 1x4, 2x2, 4x1
Thermal Design Power (TDP)	15 W
Configurable TDP-up frequency	1.8 GHz
Configurable TDP-down frequency	0.8 GHz
Maximum number of PCI Express lanes	12
Processor code	SR3LA
Processor ARK ID	124967
Processor package size	42 X 24 mm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Intel Identity Protection Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00

Weight and Dimensions

Depth	234.3 mm
Width	326 mm
Height	17.9 mm
Weight	1480 g
