EN - 6
CONTROLS LOCATION
1. Front brake lever
2. Throttle twistgrip
3. Rear brake control pedal
4. Starting device
5. Fuel tank ller cap
6. R.H. switch (engine electric starting)
7. Rear shock absorber spring preload ad-
juster
8. Fuel cock
9. Gear shift pedal
10. L.H. switch
11. Clutch control lever
KEYS
Two keys are supplied with the motorcycle
(one of them is a spare key) to be used:
a) on ignition switch;
b) on steering lock.

Husqvarna TE125 2011 Specifications

General

Engine Type	Single cylinder, 2-stroke
Displacement	124.8 cc
Cooling System	Liquid cooled
Transmission	6-speed
Front Tire	90/90-21
Rear Tire	120/90-18
Starter	Kickstarter
Bore x Stroke	54 mm x 54.5 mm
Front Suspension	48 mm
Rear Suspension	WP monoshock
Front Brake	Single disc
Rear Brake	Single disc
Fuel Capacity	8.5 L
Wheelbase	1, 475 mm
Seat Height	970 mm
Fuel System	Carburetor. Keihin PWK 36
Ignition	Electronic ignition (CDI)
