InstallatIon
3-12 HPR400XD Auto Gas – 806160
A strap kit (228336) for lifting the HPR400XD is available from Hypertherm. The strap kit should only be used to lift the
HPR400 as outlined herein. Before using the strap kit, the customer understands and assumes exclusive responsibility
for supplying personnel trained and qualified to operate forklifts, cranes, hoists and other lifting devices to lift or move
the power supply. All movement of the power supply must be done in compliance with applicable local laws and
regulations. All handling equipment must be evaluated for each application and inspected and tested before each use.
The power supply can be moved by forklift, but the forks must be long enough to extend the entire length of the base.
Take care when lifting so that the underside of the power supply is not damaged. The customer agrees to observe and
ensure compliance with the following:
 • Thestrapsandotherhandlingequipmentmustcomplywithapplicablelocalstandards,lawsandregulations.
 • Theratedcapacity,designfactor,andefciencyratingoftheliftingsystem,includingthestrapssoldby
Hypertherm, may be affected by wear, misuse, overloading, corrosion, deformation, intentional alteration, age, and
other use conditions. An inspection of the straps by qualified personnel should be conducted before each use.
Worn or damaged straps may not be used, nor may they be altered or modified in any way.
 • All4loopsattheendsofthestrapsmustbesecurelyandproperlyattachedtotheliftingmechanism.
 • Thepowersupplyisanonsymmetricalload;ensurethatananalysisbyaqualiedpersonisperformedproperlyto
balance the load to prevent tipping and overloading of any one strap.
 • Allenclosurepanelsmustbesecurelyfastenedbeforeliftingthepowersupply.
 • Theliftingmechanismmustberatedfortheappropriateweightandbesuitableforthestrapsize.
 • Eachstrapshouldpassthroughall4holesinthebaseofthepowersupplyandshouldnotbetwisted,
constricted, bunched or pinched.
 • Strapsshallnotbeshortenedorlengthenedbyknotting,twisting,chokerhitching,orothermeans.
 • Thepowersupplyshouldbeliftedslowly,notmorethan203mm(8in.)abovetheoor,toinsurethattheweight
is evenly distributed.
 • Thepowersupplyshouldbemovedslowlytopreventsuddenaccelerationanddecelerationwhenmoving.
 • Accesstotheareashouldberestrictedwhenmovingorliftingtopreventinjuryofpersonnelifthepowersupply
shifts or tips.
Correct path for lifting straps
DANGER
The HPR400XD power supply weighs approximately 746 kg (1645 lbs). 1 or 2 person manual pushing
or lifting could cause injury. Use appropriate lifting aids and techniques when moving a power
supply
Lifting the power supply
