Hypertherm Powermax30 XP Service Manual

134 Powermax30 XP Service Manual 808150 Revision 0
6 – Power Supply Component Replacement
3. Locate the 3-pin connector at the TORCH START slot (J12) on the power board (on the side facing the heatsink)
where the orange, blue, and purple wires from the torch lead connect.
Figure 68
2
1
1
TORCH START slot (J12)
2
Front panel
