FEATURES OF YOUR HYUNDAI
100
CLIMATE CONTROL AIR FILTER
(IN FRONT OF BLOWER UNIT)
B760A06GK-GAT
(If Installed)
B760A01E
Evaporator core
Filter
Heater core
Outside air
Inside air
Inside air
Blower fan
The climate control air filter is located in
front of the blower unit behind the glove
box.
It operates to decrease the amount of
pollutants entering the car.
To replace the climate control air filter,
refer to the page 6-19.
CAUTION:
o Replace the filter every 15,000 km
(10,000 miles) or once a year.
If the car is being driven in severe
conditions such as dusty, rough
roads, more frequent climate con-
trol air filter inspections and
changes are required.
o When the air flow rate is decreased,
it must be checked at authorized
dealer.
!
ANTENNA
B870A01A
!
B870A01A-GAT
Fixed Rod Antenna
Your car uses a fixed rod antenna to
receive both AM and FM broadcast
signals.
This antenna is a removable type. To
remove the antenna, turn the antenna
counterclockwise. To install the an-
tenna, turn the antenna clockwise.
CAUTION:
Be sure to remove the antenna be-
fore washing the car in an automatic
car wash or the antenna may be
damaged.
