6
DO-IT-YOURSELF MAINTENANCE
27
G290B02GK-GAT
Adjustment After Headlight As-
sembly Replacement
If the vehicle has had front body repair
and the headlight assembly has been
replaced, the headlight aiming should
be checked using an aiming screen as
shown in the illustration. Turn on the
headlight switch.
1. Adjust headlights so that main axis
of light is parallel to center line of
the body and is aligned with point
"P" shown in the illustration.
2. Dotted lines in the illustration show
the center of headlights.
SPECIFICATION:
"H"
Horizontal center line of headlights
from ground:
Low Beam: 690 mm (27.2 in.)
High Beam: 674 mm (26.5 in.)
"W"
Distance between each headlight cen-
ter :
Low Beam: 1,336 mm (52.6 in.)
High Beam: 1,098 mm (43.2 in.)
"L"
Distance between the headlights and
the wall that the lights are tested
against : 3,000 mm (118 in.)
G290B01HR-1
H
Ground
line
30mm (1.18 in.)
L
Cut-off line
"P"
Horizontal line
H
W
Vertical line
REPLACEMENT OF LIGHT
BULBS
G260A01MC-AAT
Before attempting to replace a light
bulb, be sure the switch is turned to
the "OFF" position.
The next paragraph shows how to
reach the light bulbs so they may be
changed. Be sure to replace the burned-
out bulb with one of the same number
and wattage rating.
See page 6-36 for the wattage descrip-
tions.
CAUTION:
o Keep the lamps out of contact
with petroleum products, such as
oil, gasoline, etc.
o If you don't have necessary tools,
the correct bulbs and the exper-
tise, consult your authorized
Hyundai dealer.
!
To Next Page
