Notches
What to do next:
v Replace the AGP adapter and adapter slot cover latch.
v To work with another option, go to the appropriate section.
v To complete the installation, go to “Completing the installation” on
page 66.
Installing adapters
This section provides information and instructions for installing and removing
adapters.
Adapter slots
The small form factor desktop model has two expansion slots used to connect
adapters to the peripheral component interconnect (PCI) bus. You can install an
adapter up to 174.6 mm (6.875 inches) long in the small form factor desktop
model.
The desktop model has three expansion slots used to connect adapters to the
peripheral component interconnect (PCI) bus and one slot used to connect an
accelerated graphics port (AGP) adapter. You can install an adapter up to 330
mm (13 inches) long in the desktop model.
All adapters supported by your computer use Plug and Play technology that
enables the computer to automatically configure the adapter. For more
information, see “Updating the computer configuration” on page 67.
Chapter 5. Installing options 53
