8-6
Chapter 8: Adding and replacing system board components
Removing memory modules
To remove a DIMM, press the holding clips on both sides of
the socket outward to release the DIMM.
Verifying the system memory
To view the system memory settings in Setup, select
System Information
from the Setup main menu. See the
section “Viewing system information and product data” on
page 5-5 for information about this option.
Replacing the system battery
Follow these steps to replace the battery:
1.
Press the securing clip on the battery socket to release
the battery.
2.
Lift the battery from the socket.
3.
Insert a new 3V lithium battery (CR2032) into the
socket and press it down until the securing clip clicks
and locks the battery in.
Important:
Make sure you insert the battery with the positive side
on top. A plus (+) sign indicates the positive side.
v65xahb.book : chap-8.fm Page 6 Friday, January 16, 1998 4:27 PM
