Installing the CD-ROM Drive
Installing the CD-ROM Drive
760
CD
Attention:
Make sure that any locking device is
unlocked.
The CD-ROM and diskette drives are
very delicate devices that need
careful handling. Do not press on,
drop, or apply any shock to the
drives when they are removed from
the computer.
To remove the diskette drive from the UltraBay and install the
CD-ROM drive:
1
Make sure that no diskette is in the diskette drive.
2
Open the LCD; then open the keyboard.
3
Lift the handle on the diskette drive with the plastic tape, and
remove the diskette drive.
4
Remove the front bezel from the
inside
of the computer.
a) Slide the lever 1 on the bezel to the right as shown.
b) Pull the upper portion of the bezel the remove the bezel.
1
2
3
Note:
If you are using DOS or Windows,
the diskette drive can be removed
without turning off the computer.
Refer to the documents supplied with
your operating systems.
134 IBM ThinkPad 760E, 760ED, or 760EL User's Guide
