System Resources
System Resources IRQ I/O Address (Hex)
Memory Address
(Hex)
DMA
Channel
SCSI Controller in
Dock II
11, 9, 10, or 12 340–35F or 140–14F DC000–DFFFF,
CC000–CFFFF,
C8000–CBFFF,
D0000–D3FFF,
D4000–D7FFF,
D8000–DBFFF, or
disabled
None
SCSI Controller in
SelectaDock Docking
System
11, 3, 4, 5, 7, 9,
10, 15, or
disabled
(Automatically set by the
system)
None None
IDE hard disk drive or
IDE CD-ROM drive in
the Docking Station
15 0170–0177 and 0376–0377 None None
ISA adapter card
(option card) in the
docking station
(Refer to manual that came with the adapter card.)
PCI adapter card
(option card) in the
SelectaDock Docking
System
11, 3, 4, 5, 7, 9,
10, 15, or
disabled
(Refer to manuals that came with the adapter card.)
Note:
Select an IRQ and
the memory addresses
with the jumper and
DIP switches on the
system board of the
Dock I or Dock II. See
“Using SCSI Controller
and Support Software”
in the
Dock I User's
Guide
or Dock II
User's Guide
. Do not
select Disabled when
OS/2 is used.
Note:
Enhanced
Video features
and PCI adapter
card in the
SelectaDock
Docking System
share the same
IRQ11.
Sound Blaster
and MIDI share
the same IRQ.
Note:
Addresses in the
parentheses are also used
when ECP is enabled by the
ThinkPad Features program
as the printer operating mode.
Memory-mapped I/O
Note:
Memory upper than
the system memory
will be automatically
set by the system.
Note:
When you
enable ECP
as the printer
operating
mode by
ThinkPad
Features
program,
one of the
choices
(including
“disabled”)
must be
selected.
274 IBM ThinkPad 760E, 760ED, or 760EL User's Guide
