Off mode power (watts):
6
Noise levels (the declared A-weighed sound power level of the computer):
See Acoustical noise emissions.
Test voltage and frequency:
230V/50Hzor60Hz
Total harmonic distortion of the electricity supply system:
The maximum harmonic content of the input voltage waveform will be
equal or less than 2%. The qualification is compliant with EN 61000-3-2.
Information and documentation on the instrumentation set-up and circuits used
for electrical testing:
ENERGY STAR Test Method for Computer Servers; ECOVA Generalized
Test Protocol for Calculating the Energy Efficiency of Internal Ac-Dc and
Dc-Dc Power Supplies.
Measurement methodology used to determine information in this document:
ENERGY STAR Servers Version 2.0 Program Requirements; ECOVA
Generalized Test Protocol for Calculating the Energy Efficiency of Internal
Ac-Dc and Dc-Dc Power Supplies.
What your server offers
The server uses the following features and technologies.
v Integrated management module II (IMM2)
The integrated management module II (IMM2) is the second generation of the
IMM. The IMM2 is the common management controller for IBM System x
hardware. The IMM2 consolidates multiple management functions in a single
chip on the server system board.
Some of the features that are unique to the IMM2 are enhanced performance,
expanded compatibility with blade servers, higher-resolution remote video,
expanded security options, and Feature on Demand enablement for hardware
and firmware options.
For additional information, see “Using the Integrated Management Module II
(IMM2)” on page 105 and the Integrated Management Module II User’s Guide at
http://www-947.ibm.com/support/entry/portal/docdisplay?lndocid=migr-
5086346.
v UEFI-compliant server firmware
The IBM System x Server Firmware offers several features, including Unified
Extensible Firmware Interface (UEFI) version 2.1 compliance, enhanced
reliability, availability, and serviceability (RAS) capabilities, and basic
input/output system (BIOS) compatibility support. UEFI replaces the legacy
BIOS. UEFI defines a standard interface between the operating system, platform
firmware and external devices, and offers capabilities that far exceeds that of the
legacy BIOS.
The server design combines the UEFI capabilities and features with legacy BIOS
compatibility. The server is capable of booting UEFI-compliant operating
systems, BIOS-based operating systems, and BIOS-based adapters as well as
UEFI-compliant adapters.
Note: The server does not support DOS (Disk Operating System).
v Dynamic System Analysis (DSA)
14 System x3100 M5 Type 5457: Installation and Service Guide
