FOREWORD
Thank you for purchasing this Icom radio. The IC-2300H FM
TRANSCEIVER is designed and built with Icom’s state of the
art technology and craftsmanship. With proper care this radio
should provide you with years of trouble-free operation.
D FEATURES
❍ 65 W* — high transmit output power
(*except Korea/Taiwan versions)
❍ Tone squelch, DTCS squelch standard
❍ Three color (amber, yellow & green) back-
lightLCD screen
❍ Remote control microphone available
IMPORTANT
READ ALL INSTRUCTIONS carefully and completely
before using the transceiver.
SAVE THIS INSTRUCTION MANUAL— This
instruction manual contains important operating instructions
for the IC-2300H.
EXPLICIT DEFINITIONS
Icom, Icom Inc. and the Icom logo are registered trademarks of Icom
Incorporated (Japan) in Japan, the United States, the United King-
dom, Germany, France, Spain, Russia and/or other countries.
SUPPLIED ACCESSORIES
q Microphone (HM-133V)* . . . . . . . . . . . . . . . . . . 1
w Fuse (20 A) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
e DC power cable (3 m) . . . . . . . . . . . . . . . . . . . . . 1
r Mobile mounting bracket . . . . . . . . . . . . . . . . . . 1
t Mounting screws, nuts and washers . . . . . . .1 set
y Microphone hanger
†
. . . . . . . . . . . . . . . . . . . . . . 1
*The supplied microphone may differ, depending on the version.
†
Not supplied, depending on the version.
q*
w
e
r
t
y
†
OPTIONS
HM-133V REMOTE-CONTROL MICROPHONE
HM-154 HAND MICROPHONE
SP-10 EXTERNAL SPEAKER
OPC-440A MIC EXTENSION CABLE
OPC-589 ADAPTER CABLE
OPC-1132A/OPC-347 DC POWER CABLES
CS-2300H CLONING SOFTWARE
OPC-478/OPC-478UC CLONING CABLES
OPC-474 CLONING CABLE
WORD DEFINITION
R WARNING!
Personal injury, fi re hazard or electric
shock may occur.
CAUTION
Equipment damage may occur.
NOTE
Recommended, only inconvenience.
No risk of personal injury, fi re or elec-
tric shock.
FCC INFORMATION
• FOR CLASS B UNINTENTIONAL RADIATORS:
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not in-
stalled and used in accordance with the instructions, may
cause harmful interference to radio communications.
However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does
cause harmful interference to radio or television recep-
tion, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment
and receiver.
• Connect the equipment into an outlet on a circuit dif-
ferent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV
technician for help.

Icom IC-2300H Specifications

General

Radio type	Portable
Supported radio bands	FM
RMS rated power	65 W
Display type	LCD
Backlight color	Amber/Yellow/Green
Built-in display	Yes
Headphone connectivity	3.5 mm
Product color	Black
Power source	DC
Operating temperature (T-T)	-10 - 60 °C

Weight and Dimensions

Depth	162 mm
Width	140 mm
Height	40 mm
Weight	1100 g
