Icom IC-2300H User Manual

Previous view
50
11
OTHER FUNCTIONS
Weather channel operation ■
Weather channel selection D
q Push [M/CALL] several times to select the weather
channel group.
w Rotate [DIAL] to select the desired weather chan-
nel.
e Push [M/CALL] to select the memory mode, or push
[V/MH z] to select the VFO mode.
Weather Alert function D
NOAA broadcast stations transmit weather alert tones
before important weather announcements. When the
Weather Alert function is turned ON, the transceiver
checks the selected weather channel every 5 seconds.
for an announcement. When the alert signal is detect-
ed, the “AL.T” and the WX channel are displayed al-
ternately and a beep tone sounds until the transceiver
is operated. The selected (used) weather channel is
checked periodically during standby or while scanning.
q Select the desired weather channel.
w Push [SET] to enter the Set mode.
e Push [SET] or [MONI] to select the weather alert
item, and then rotate [DIAL] to select “ON."
r Push any key other than [SET] or [MONI] to save
the selection and exit the Set mode.
t Set the desired stand-by mode.
• Select the VFO, memory channel or Call channel.
• Scan or priority watch operation can be also se-
lected.
y When the alert is detected, a beep sounds and the
following will be displayed.
LOCK
S E T
ANM
MONI
DUP
LOW
T
-
SCAN
TONE
PRIO
M/CALL
SCAN
V/MHz
DIGITAL
PRIO
AO
BUSY
MUTE
NAR
MID
LOW
Weather channel number
LOCK
S E T
ANM
MONI
DUP
LOW
T
-
SCAN
TONE
PRIO
M/CALL
SCAN
V/MHz
DIGITAL
PRIO
AO
BUSY
MUTE
NAR
MID
LOW
LOCK
S E T
ANM
MONI
DUP
LOW
T
-
SCAN
TONE
PRIO
M/CALL
SCAN
V/MHz
DIGITAL
PRIO
AO
BUSY
MUTE
NAR
MID
LOW
Alternately displays above indications.
When the weather alert is detected:
NOTE: While receiving a signal on a frequency other
than the weather channel, the receiving audio will be
momentarily interrupted approximately every 5 sec-
onds, when the alert function is turned ON. This is
caused by the Weather Alert function. To cancel
these interruptions, turn OFF the Weather Alert func-
tion in the Set mode.
Only USA versions

Icom IC-2300H Specifications

General

Radio type	Portable
Supported radio bands	FM
RMS rated power	65 W
Display type	LCD
Backlight color	Amber/Yellow/Green
Built-in display	Yes
Headphone connectivity	3.5 mm
Product color	Black
Power source	DC
Operating temperature (T-T)	-10 - 60 °C

Weight and Dimensions

Depth	162 mm
Width	140 mm
Height	40 mm
Weight	1100 g
